Engine Tooling

856A3501G04 – FIXTURE, ALIGNMENT-GUIDE-BOOSTER/LPT SHAFT

FIXTURE, ALIGNMENT-GUIDE-BOOSTER/LPT SHAFT

SKU 856A3501G04 Category Engine Tooling

FIXTURE, ALIGNMENT-GUIDE-BOOSTER/LPT SHAFT

Usage	This fixture is used to align and guide the booster and low-pressure turbine (LPT) shaft accurately during assembly or maintenance operations.

Dimensions	70x70x25
Weight	25
Usage	This tool is a holding fixture used to support and secure the PT rotor to the TRF during maintenance or assembly operations.

Dimensions	70x45x35
Weight	40
Usage	This tool is an adapter bracket assembly used to properly align and support the aft shaft during installation or removal of the PT (power turbine) rotor.
