Engine Tooling

856A3409G01 – PIN GUIDE KIT SPINNER CONE ENGINE

PIN GUIDE KIT SPINNER CONE ENGINE

SKU 856A3409G01 Category Engine Tooling

PIN GUIDE KIT SPINNER CONE ENGINE

Usage	This pin guide kit is used to properly align and position the spinner cone on the engine during installation or removal.

Dimensions	60x20x30
Weight	25
Usage	This tool is a drop-check fixture used to inspect and verify the proper positioning of the aft PT rotor during maintenance or assembly.

Dimensions	70x45x35
Weight	40
Usage	This tool is an adapter bracket assembly used to properly align and support the aft shaft during installation or removal of the PT (power turbine) rotor.
